MŰSZAKI SPECIFIKÁCIÓK
WORKING AREA
Distance between centers	1500 mm
Swing diameter over table	380 mm
Max. grinding diameter	360 mm
Max. workpiece weight	150 kg
Grinding head swivel angle	60° °
AXES:
X axis	270 mm
Max. rapid traverse	10 m/m
Heidenhain linear scale resolution	0.05 μm
Minimum increment	0.0001 mm
Z axis	1850 mm
HANDWHEEL
GRINDING WHEEL
Size	500 × 50 × 152.4 mm
Speed	1250 (1650 opt) rpm
SPINDLE
Swivel angle range	90 °
Internal taper	MT4 (opt MT5)
Speed range	10-600 rpm
TAILSTOCK
Internal taper	MT4 (opt MT5)
Stroke	mm
TABLE
Swivel angle range	±5° °
MOTOR
Grinding motor power	kW
Lubrication unit power	0.2 kW
Hydraulic motor power	0.38 kW
Coolant pump motor power	0.2 kW
INSTALLATION
Net weight	6400 kg
Gross weight	7200 kg
Structure	CNC Angular Wheelhead

ALAPTARTOZÉKOK ÉS OPCIÓK
STANDARD ACCESSORIES:
Grinding wheel and wheel flange
Carbide center
Adjustable tailstock
Semi-enclosed splash guard
LED work light
Tools and toolbox
Electrical wiring diagram
Workhead driven by servo motor
X and Z axes with servo motor control
MPG handwheel (2-axis control)
Diamond dresser and holder
Automatic grinding wheel dressing cycle
Standard coolant tank and coolant system
Electrical cabinet with heat exchanger
Operation manual and spare parts list
4-color status indicator light
NCT CNC control
Angular wheelhead with CNC control
X-axis linear scale (Heidenhain / Mitsubishi)
OPTIONS:
Wheel balancing stand
Special diamond dresser (rotary / multi-point)
5C collet system for workhead
Higher capacity coolant tank
Magnetic separator for coolant system
Centralized lubrication system
Anti-vibration machine mounts
Special electrical configuration (voltage / standards)
Internal grinding attachment (ID grinding)
Automatic grinding wheel balancing system
Different center types (carbide center, live center)
Fine filtration system for coolant
Fully enclosed or full splash guard
Automatic size control system (in-process / post-process)
Automatic workpiece loading interface
Additional dressing axes and dressing configurations
Additional CNC grinding cycles (taper grinding / combined cycles)
